Modular Street Light

Modular LED Road Light

Name: Modular LED Road Light
Brand: Yakeen Lighting
Availability: InStock

60-300W modular design with IP66 and IK08

Wattage

60W-300W

Efficacy

140-160 lm/W

IP Rating

IP66

Warranty

5 years

Yakeen modular LED road light, 60-300W, 140-160 lm/W, IP66, IK08, tool-free modular lens replacement, SASO & G-Mark certified for urban road lighting.

SASO G-Mark CE RoHS

MOQ

50 pieces

Lead Time

15-25 days

Get Your Quote → WhatsApp

Applications

Where Modular Street Light Shines

Urban Roads

High-efficiency lighting for city streets and boulevards.

Highways

Powerful, uniform illumination for high-speed roads.

Parking Areas

Area lighting for large outdoor parking.

Industrial Zones

Durable lighting for industrial area roads.

Technical Specifications

Product technical specifications
Parameter	Value
Wattage	60W-300W
Luminous Efficacy	140-160 lm/W
Color Temperature	3000K / 4000K / 5000K / 5700K
CRI	Ra>70
Beam Angle	Type III / Type V
IP Rating	IP66
Dimming	0-10V / DALI / NEMA socket
Lifespan	L70 > 50,000 hours
Warranty	5 years
Certifications	SASO, G-Mark, CE, RoHS
MOQ	50 pieces
Lead Time	15-25 days

Key Features

Modular LED engine (tool-free replacement)
Interchangeable lens modules (Type III/V)
Aluminum die-cast housing with鏁ｇ儹 fins
IK08 impact-resistant tempered glass
NEMA photocell socket (dusk-to-dawn)
Adjustable arm bracket (0-90 degrees)

Technical Options

Dimming: 0-10V / DALI / NEMA socket
Lifespan: L70 > 50,000 hours
CRI: Ra>70
Beam Angle: Type III / Type V

FAQ

Modular Street Light Questions

What is the recommended pole height and spacing?

60W: 4-6m height, 20-25m spacing. 150W: 6-8m height, 30-35m spacing. 300W: 8-12m height, 40-50m spacing. Yakeen Lighting provides free DIALux road lighting simulation.

Does it support smart city integration?

Yes. NEMA 7-pin socket supports smart photocell, ZigBee, or LoRaWAN controllers for remote dimming and monitoring. Compatible with major smart city platforms.
